Magic Mirror Display (WD-PM)

  • WD-PMW/PMA/PMM series
  •  10.1/13.3/21.5/32/43/49/55/65 Inch
  • Non-touch/Capacitive touch
  • Android/Windows/Linux OS/Monitor
Category:

Description

Size 10.1″13.3″21.5″32″43″49″55″65“ LCD screen
Resolution 1920×1080
Touch Non-touch panel
Capacitive touch panel
Touch effect Water stains and dirt do not affect touch accuracy
CPU Android: A64/RK3288/RK3566/RK3568/RK3588/RK3399(Optional)
Windows: J1900/J4125/J6412/I3/I5/I7  1st~14th(optional)
Memory&Storage Android: 1GB/2GB/4GB RAM
8G/16G/32G/64G ROM
Windows: 4G/8G/16G DDR3/DDR4 RAM
64G/128G/256G/500G/1T/2T SSD
OS Android 6.0/8.1/11.0/12.0/13.0/Linux/Debian/QT
Windows 7/8/10/11/Linux
Network WiFi; Ethernet; Bluetooth
Interface Android: SD/TF,HDMI,USB,RJ45/POE,OTG,DC,U-boot,Ear+Mic,Speakers,Serial port
Windows: DC,HDMI,VGA,USB,RJ45,Audio,COM,Speakers,Serial port
Monitor: DC,VGA, HDMI, DVI,Audio, Speakers
Type Circular, Elliptical, Square, Rectangular
Installation Wall mounted & Floor standing
Storage temperature -20℃~60℃
Power supply AC(100-240)V/50-60HZ
Maximum power <100W
AC power cord, WIFI antenna, Key, Base, Carton
The surface is 3MM mirror glass, the frame is aluminum alloy profile, and the back shell is 1.5MM sheet metal
